| General | |
|---|---|
| Frequency Range | 400-470MHz; 136-174MHz |
| Channel Capacity | 128 |
| Zone Capacity | 8 |
| Operating Voltage | 7.4V(rated) |
| Battery | 1500mAh 7.4V; 2200mAh 7.4V (Optional) |
| Battery Life (5/5/90 Duty Cycle, High TX Power) | 12h (1500mAh); 16h (2200mAh) |
| Dimensions (H x W x D) mm | 115 x 55 x 29.5mm |
| Weight(with antenna&battery) | About 230g |
| Display | 1.44 inch monochrome LCD |
| Environmental | |
|---|---|
| Operating Temperature | -30℃*~+60℃ |
| Storage Temperature | -40℃~+85℃ |
| Dust and Water Intrusion | IP54 |
