General |
||
|
Frequency Range |
UHF: 400-440MHz , 430-470MHz, 446MHz |
|
|
Channel Capacity |
256 |
|
|
Channel Spacing |
25/12.5KHz |
|
|
Zone Capacity |
16 |
|
|
Operating Voltage |
3.7 |
|
|
Battery (5-5-90 Duty Cycle, High TX Power) |
2000mAh (Li-Ion) |
|
|
Battery Life (5/5/90 ) |
Digital: approximately 12 hours; Analogue: approximately 10 hours |
|
|
Frequency Stability |
±0.5ppm |
|
|
Antenna Impedance |
50Ω |
|
|
Dimensions |
106 x 54 x 23mm |
|
|
Weight |
160g |
|
|
Transmitter |
||
|
RF Power Output |
UHF High power: 3W; UHF Low power: 1.5W |
|
|
FM Modulation |
11K0F3E @ 12.5KHz, 16K0F3E @ 25KHz |
|
|
4FSK Digital Modulation |
12.5kHz Data Only: 7K60FXD 12.5kHz Data & Voice: 7K60FXW |
|
|
Conducted/Radiated Emission |
-36dBm<1GHz -30dBm>1GHz |
|
|
Modulation Limiting |
±2.5KHz @ 12.5KHz, ±5.0KHz @ 25KHz |
|
|
FM Noise |
40dB @ 12.5KHz, 45dB @ 25KHz |
|
|
Adjacent Channel Power |
60dB @ 12.5KHz 70dB @ 25KHz |
|
|
Audio Response |
+1 ~ -3dB |
|
|
Audio Distortion |
≤3% |
|
|
Digital Vocoder Type |
AMBE++ |
|
|
Digital Protocol |
ETSI-TS102 361-1，2&3 |
|
|
Receiver |
||
|
Sensitivity |
Analog |
0.22μV (12dB SINAD) 0.22μV (Typical) (12dB SINAD) 0.4μV (20dB SINAD) |
|
Digital |
0.22μV /BER5% |
|
|
Adjacent Selectivity TIA-603 ETSI |
60dB @ 12.5KHz / 70dB @ 25KHz 60dB @ 12.5KHz / 70dB @ 25KHz |
|
|
Spurious Response Rejection TIA-603 ETSI |
70dB @ 12.5/25KHz 70dB @ 12.5/25KHz |
|
|
Inter-modulation TIA-603 ETSI |
70dB @ 12.5/25KHz 65dB @ 12.5/25KHz |
|
|
Hum & Noise |
40dB @ 12.5KHz, 45dB @ 25KHz |
|
|
Rated Audio Power Output |
0.4W |
|
|
Rated Audio Distortion |
<5% |
|
|
Audio Response |
+1 ~ -3dB |
|
|
Conducted Spurious Emission |
< -57dBm |
|
|
Environmental Specifications |
||
|
ESD |
IEC 61000-4-2 (level 4) ±8kV (contact) ±15kV (air) |
|
|
Dust & Water Intrusion |
IP54 Standard |
|
|
Humidity |
Per MIL-STD-810 C/D/E/F/G Standard |
|
|
Shock & Vibration |
Per MIL-STD-810 C/D/E/F/G Standard |
|
