General data
Transmitter
Receiver
Environmental conditions
GPS (PD665G only)
| Frequency range |
VHF: 136 - 174 MHz
UHF: 400 - 527 MHz
|
| Supported operating modes |
|
| Number of channels |
1024
|
| Number of zones |
64
|
| Channel spacing |
12.5 / 20 / 25 kHz (analog)
12.5 kHz (digital)
|
| Operating voltage |
7.4 V (nominal)
|
| Battery |
1500 mAh (lithium-ion battery)
|
| Battery service life (5/5/90) |
approx. 11 hours (analog)
ca. 16 hours (digital)
|
| Frequency stability |
±0.5 ppm
|
| Antenna impedance |
50 Ω
|
| Dimensions (H×W×D, with standard battery, without antenna) |
119 x 54 x 27 mm
|
| Weight |
approx. 310 g
|
| Programmable keys | |
| LCD display |
160 × 128 pixel, 65,536 colors, 1.8 inch, 4 lines
|
| Transmitting power |
VHF: 1 / 5 W
UHF: 1 / 4 W
|
| Modulation |
11 K0F3E at 12.5 kHz
14 K0F3E at 20 kHz
16 K0F3E at 25 kHz
|
| 4FSK digital modulation |
12.5 kHz (data only): 7K60FXD
12.5 kHz (data and voice): 7K60FXW
|
| Interfering signals and harmonics |
-36 dBm < 1 GHz
-30 dBm > 1 GHz
|
| Modulation limiting |
±2.5 kHz at 12.5 kHz
±4.0 kHz at 20 kHz
±5.0 kHz at 25 kHz
|
| Hum and noise |
40 dB at 12.5 kHz
43 dB at 20 kHz
45 dB at 25 kHz
|
| Adjacent channel selectivity |
60 dB at 12.5 kHz
70 dB at 20/25 kHz
|
| Audio sensitivity |
+1 dB to -3 dB
|
| Audio distortion |
≤ 3 %
|
| Digital vocoder type |
AMBE+2™
|
| Sensitivity (analog) |
0.22 μV (12 dB SINAD)
0.22 μV (typical) (12 dB SINAD)
0.4 μV (20 dB SINAD)
|
| Sensitivity (digital) |
0.22 μV / BER 5%
|
| Adjacent channel selectivity |
TIA-603: 60 dB at 12.5 kHz / 70 dB at 20 and 25 kHz
ETSI: 60 dB at 12.5 kHz / 70 dB at 20 and 25 kHz
|
| Intermodulation |
TIA-603: 70 dB at 12.5/20/25 kHz
ETSI: 70 dB at 12.5/20/25 kHz
|
| Spurious response rejection |
TIA-603: 70 dB at 12.5/20/25 kHz
ETSI: 70 dB at 12.5/20/25 kHz
|
| Signal-noise ratio (S/N) |
40 dB at 12.5 kHz
43 dB at 20 kHz
45 dB at 25 kHz
|
| Nominal audio power output |
0.5 W
|
| Audio distortion |
≤ 3 %
|
| Audio sensitivity |
+1 dB to -3 dB
|
| Conducted spurious emission |
< -57 dBm
|
| Operating temperature range |
-30 °C to +60 °C
|
| Storage temperature range |
-40 °C to +85 °C
|
| ESD |
IEC 61000-4-2 (level 4)
±8 kV (contact) ±15 kV (air)
|
| Protection against dust and moisture |
IP67
|
| Shock and vibration resistance |
MIL-STD-810 C/D/E/F/G
|
| Relative humidity |
MIL-STD-810 C/D/E/F/G
|
| Time to first fix (TTFF) cold start |
< 1 minute
|
| Time to first fix (TTFF) warm start |
< 10 seconds
|
| Horizontal accuracy |
< 10 meter
|
