General data

Frequency ranges	380 – 430 MHz / 806 – 870 MHz
Dimensions (H × B × T)	141 × 55 × 39 mm
Weight	approx. 515 g(with 1800 mAh battery and antenna)
Operating voltage	7.4 V
Battery (lithium-ion battery)	1800 mAh (standard battery)
Battery service life (5/5/90 duty cycle)	Approx. 14 hours (standard battery)
Maximum audio power output	> 1.2 W

User interface

LCD display	1.8 zools, 160 x 128 pixels, 65,536 colors
Call group number – TMO
Call group number – DMO
Phone book	1000 entries
Group lists – TMO (use for scanning, scan lists)	200 (200 groups per list)
Group lists – DMO	50 (200 groups per list)
Number of short messages (SDS) / (input, output, drafts)	400 / 50 / 50
Number of status messages

Environmental conditions

Operating temperature range (in non-hazardous environment)	-30 °C to +60 °C
Operating temperature range (in hazardous environment)	-20 °C to +55 °C
Storage temperature range	-40 °C to +85 °C
Relative humidity	ETS 300 019 (95 %)
Protection against dust and moisture	IEC60529, IP67
Shock and vibration resistance	MIL-STD-810 F/G
Explosion protection	Gas: II 1G Ex ia IIC T4 Dust: II 1D Ex ia IIIC T120 °C IP6x Mining: I M1 Ex ia

Radio characteristics

Channel spacing	25 kHz
Transmitting power	1 W
Transmitting power accuracy	±2 dB
Receiver class	ETSI EN 392-2 / 396-2 class A
Static receiver sensitivity	-112 dBm (typical -116 dBm)
Dynamic receiver sensitivity	-103 dBm (typical -105 dBm)

GNSS (GPS / GLONASS / Beidou)

Sensitivity	≤ -144 dBm receiving sensitivity ≤ -157 dBm signal tracking sensitivity
Precision	≤ 10 m
TTFF (Time To First Fix) cold start	< 50 s
TTFF (Time To First Fix) warm start	< 1 s
